CUBESX-HSE-2 Satellite

CUBESX-HSE-2
CUBESX-HSE-2
CUBESX-HSE-2
CUBESX-HSE-2
CUBESX-HSE-2
CUBESX-HSE-2
CUBESX-HSE-2
Name CUBESX-HSE-2 (HSE-2, RS21S, Space-PI 13, Space π)
Form factor CubeSat
Units or mass 3U
Mass in kg 3.39 kg
Status Reentry 2024-05-09. Was operational (As per on SpacePI website last checked 2022-12-26)
Launched 2022-08-09
NORAD ID 53383
Deployer 12U Deployer [Aerospace Capital]
Launcher Sojuz
Organization Higher School of Economics
Institution University
Entity Academic / Education
Nation Russia
Manufacturer AIVT by Sputnix
Operator Sputnix
Oneliner

Monitoring of the Arctic, tests of the plasma engine.

Description

16 different satellite missions within the framework of the Space-PI project with the participation of students and schoolchildren.

HSE-2 is a satellite with the AIS hardware and software system on board. It receives navigational data from ships. The collected information from the spacecraft is transmitted to ground stations and processed. After launching into orbit, satellites are controlled by the Mission Control Centers of the National Research University Higher School of Economics and SPUTNIX. With the help of the device, you can track and correct the routes of ships, including along the Northern Sea Route.

The satellite is equipped with a MEPhI plasma engine. An experiment will be conducted with him to correct the orbit, which gradually decreases during the flight due to friction against the upper atmosphere.

Sources [1] [2] [3] [4] [5] [6] [7] [8] [9]
Photo sources [1] [2] [3] [4] [5]
COTS subsystems
  • PLATFORM - Sputnix
Keywords AIS, Propulsion
On the same launch

Last modified: 2024-05-29
